| Model Version | GS105D 4.0 |
|---|
| Interfaces | Gigabit RJ45 Ports | 5 |
|---|
| LED | - Power
- Speed/Link/Act of Each Ethernet Port
|
|---|
| Power Interfaces | DC Jack |
|---|
| Performance | Copper Speed and Distance | - Cat. 3 or higher cable: 100 meters at 10 Mbps
- Cat. 5 or higher cable: 100 meters at 100 Mbps
- Cat. 5e or higher cable: 140 meters at Gigabit
|
|---|
| MAC Address Table | 2048 |
|---|
| Max Switching Capacity | 10 Gbps |
|---|
| Max Forwarding Rate | 7.44 Mpps |
|---|
| Jumbo Frame | 15 KB |
|---|
| Packet Buffer | 3 Mbit |
|---|
| Power | Basic Power Saving | True |
|---|
| Power Methods | DC |
|---|
| Power Input | 5V?0.55A |
|---|
| Power Adapter in the Box | Input: 100-240V~, 50/60Hz
Output: 5V?0.55A |
|---|
| Max Power Consumption | 2W |
|---|
| Idle Power Consumption | 1.4W |
|---|
| Switching | 802.3 Protocols | - 802.3x Flow Control
- 802.3i 10BASE-T
- 802.3u 100BASE-TX
- 802.3ab 1000BASE-T
|
|---|
| Reliability | EMS | IEC/EN 61000-4-2, Level 2 ESD: Contact: 4kV; Air: 8kV
IEC/EN 61000-4-5, Level 3 Surge: 2kV |
|---|
| Environment | Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing |
|---|
| Mechanical | Dimension | 88×52.5×24 mm
3.46×2.07×0.94 inches |
|---|
| Product Weight | 52 g (1.83 oz.) |
|---|
| Casing Material | Plastic |
|---|
| Installation | |
|---|
| Package Content | - GS105D
- Power Adapter
- Installation Guide
|
|---|
| Ordering Information | Retail Package Dimension | EU/US:
92×88×57 mm
3.62×3.46×2.24 inches |
|---|
| Retail Package Weight | - EU: 137 g (4.83 oz.)
- UK: 170 g (6 oz.)
|
|---|
| Units per Carton | EU/US: 100 |
|---|
| Carton Net Weight | - EU: 13.7 kg (30.2 lbs)
- UK: 17.0 kg (37.48 lbs)
|
|---|
| Carton Gross Weight | - EU: 16.6 kg (36.6 lbs)
- UK: 18.2 kg (40.12 lbs)
|
|---|
| Carton Dimension | EU/US: 48.7×31.2×38.5 cm
19.17×12.28×15.16 inches |
|---|
